| Business DEX (UK_Defence053):— phs_and_t_specification | Date: 2010/03/09 13:18:29 Revision: 1.10 |
The information requirements table for the PHS and T Specification DEX is shown below:
|
Information requirement |
Business Object(s) |
|---|---|
| Identification of the item of supply for which the specifications are defined. | Item of Supply |
| Identification of any special to type packaging or transportation equipment required, eg packing crates or boxes. | Packaging Specification, Product Design, Document |
| Categorization of the item when packed for transportation, eg ‘Dangerous Air Cargo’ (DAC). | Packaging Specification |
| Fire classification when packed for transportation. | Packaging Specification |
| Toxicity classification when packed for transportation. | Packaging Specification |
| Dimensions, weights, centre of gravity, and/or other physical properties when packed for transportation. | Packaging Specification, Product Design, Property |
| Specification of the packaging methods together with the materials required to prevent damage or deterioration of the item of supply whilst being stored, handled and transported. | Packaging Specification, Document |
| Specification of the package marking required for the item of supply. | Packaging Specification |
| Specification of the handling instructions and procedures required to prevent damage or deterioration of the item of supply. | Handling Specification, Storage Specification, Transportation Specification, Packaging Specification, Item Transportation |
| Specification of the storage instructions and procedures required to prevent damage or deterioration of the item of supply. | Storage Specification |
| Specification of the permissible ways in which the item of supply may be transported between locations. | Item Transportation |
| Specification of the transportation instructions and procedures required to prevent damage or deterioration of the item of supply. | Transportation Specification, Item Transportation |
| Specification of all security considerations to be addressed in transportation, including susceptibility to theft. | Security Classification Assignment, Message, Support Analysis |
Table 1 — PHS and T Specification information requirements
© UK MOD 2010 — All rights reserved
