| Business DEX (UK_Defence028):— support_concept | Date: 2009/05/05 13:08:44 Revision: 1.14 |
The information requirements table for the Support Concept DEX is shown below:
|
Information requirement |
Business Object(s) |
|---|---|
| Information that is used to define the message that performs the transmission of the Support Concept information between the source and destination UK_Defence processes. | Message, Record. |
| The identification, naming, versioning and status of the Support Concept. | Support Concept, Status Assignment |
| Identification of support requirements, objectives and constraints. | Support Concept, Requirement, Constraint |
| Identification of the Support Context, for which the concept is developed. | Support Concept, Support Context |
| Updates to all support context data items as they have been refined during support concept development. | Support Concept, Support Context, Assumption, Requirement> |
| Specification of the applicable strategies to be applied when contracting for support of the PSE. | Support Concept, Support Component Option |
| Guidance on applicable lines and levels of maintenance for any major support tasks identified from initial PSE behaviour analysis | Support Concept, Line of Maintenance, Depth of Maintenance |
| Specification of the initial cost and readiness metrics to be used to assess the design and operation of the support system against the support requirements. | Support Concept, Support Component Option, Support Option, Support Component, Performance Metric |
| Requirements and recommendations of comparator studies and support analyses. | Support Concept, Document |
| Associations with relevant documents. | Support Concept, Document |
Table 1 — Support Concept information requirements
© UK MOD 2010 — All rights reserved
